Industrial Pleated Filter Element , SS Sintered Cartridge For Air Separation

Name: Industrial Pleated Filter Element SS Sintered Cartridge For Air Separation
Brand: JUMAO
Price: 1 USD

Brand Name : JUMAO

Model Number : JM-PFE2573

Certification : ISO

Place of Origin : CHINA

MOQ : 1 pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000 pcs

Delivery Time : 8-45 days

Packaging Details : Wooden Box

Media : SS 316,SS 316L ,etc.

Filter Rating : 2-1000 um

Application : Gas Filtration * Oil Filtration

Size : Customized

Shape : Cylindrical

Height : As your request

Contact Now

Industrial Pleated Filter Element , SS Sintered Cartridge For Air Separation

Stainless steel pleated filter elements/cartridges can be processed with Two Kinds of Filter Media options: Stainless Steel Micron Woven Wire Mesh Cloth or Sintered SS Fiber Web. Stainless Steel Wire Mesh Pleated Filter Elements mainly serve in filtration of high molecular polymer in the field of medicament, foodstuff, petroleum, chemical industry and electron; the filtration of the hydraulic oil and the disposal of water. The stainless steel pleated filter elements offer extended filtration area and high dirt control capacities. Coarse woven wire mesh layers are pleated with the filter media layer together to form the pleating. Then welded together.Stainless steel pleated filter elements are easy to clean, economical and have a high service life. They can be backwashed or cleaned with compressed air.

The stainless steel pleated filter elements are mainly used because of their high temperature ratings. They are used to remove suspended solids, sand, abrasive- or particularly aggressive sediments from water. They are suited for residential and industrial use cases.

CHARACTERISTICS of stainless steel pleated filter elements:

Made from stainless-steel (AISI 304)
High Temperature rating (up to 120°C)
Micron rate (nominal): 80µ

ADVANTAGES of stainless steel pleated filter elements

Filtration of suspended solids and sand
Removes abrasive- or particularly aggressive sediments from water
Usable in residential and industrial applications

Application of stainless steel pleated filter elements:

Suitable for the extreme operating enviroments,
steam filtration.
Pharmaceuticals:	Prefiltraion and decarbonate filtration.
Food & Beverages:	Viscous liquid with high temperature.
Fine Chemicals:	Strong Acid and Alkaline filtration.
Water:	Filtrate the O-zone containing water.

Filtration Effiency of stainless steel pleated filter elements:

Cartridge Code	≥90% efficiency
TI045	0.45
TI100	1
TI300	3
TI500	5
TI1000	10
TI2000	20
TI5000	50

Table 2: Operating Conditions
Cartridge Code	Max.Temperature	Max. differential pressure
TI	220 ℃(428℉)	6.0 bar(87psi)

Industrial Pleated Filter Element , SS Sintered Cartridge For Air Separation
